| Reed width |
170cm ~ 360cm |
| |
|
| Dobby |
Mechanical / Electronic (optional) |
| Machine speed |
140~220 RPM (360cm - 170cm) |
| Heald Frames |
16 to 20 pcs (optional) |
| Feeder |
2 Big Feeder & 4 Small Feeder (optional) |
| Weft selection |
6 mechanical color selector / 6 or 8 electronic color selector (optional) |
| Let-off |
Mechanical Let-off / ElectronicLet-off (optional) |
| Take-up |
Mechanical Take-up / Electronic Take-up (optional) |
| Beam Dia |
600mm 680mm 800mm (optional) |
| Drop Pin |
10000 pcs (optional) |
| Heald Wire |
10000 pcs (optional) |
| Main motor |
2.2Kw |
| Main Shaft |
45mm |
| Display Panel |
Action |
| Reed |
1 piece reed (as per customer requirement) |
| Accessories |
Cloth Roll, Half Gear, Gripper, Tapes, Oil Pump, Rapier Tape wheel (as per customer requirement) |
